The Aachen Center for integrative Lightweight Production AZL wins the JEC Innovation Award 2019 in the Category “Industry & Equipment”

Press release / March 28, 2019

This year, the Aachen Center for integrative Lightweight Production AZL GmbH won the JEC AWARD 2019 for the development of the new machine system “Ultra-Fast Consolidator Machine”. This innovative machine system is a result of an 18-months AZL Joint Partner Project, conducted in 2017-2018 by the research partners AZL Aachen and Fraunhofer Institute for Production Technology IPT in Aachen, in cooperation with industrial partner companies including Conbility, Covestro, Engel, Evonik, Fagor Arrasate, Faurecia SE, Laserline, Mitsui Chemicals, Mubea Carbo Tech, Philips Photonics, SSDT and Toyota.

AZL together with some of the project partners at the AWARD Ceremony of the JEC in Paris on March 13th 2019 (from left to right): Dr. Günther Derra (Philips Photonics), Dr. Michael Emonts (Managing Director of AZL), Javier Acosta (Fagor Arrasate), Christos Karatzias (Mitsui Chemicals)
Ultra-Fast Consolidator Machine System at AZL, Aachen (Germany)

The new UItra-Fast Consolidator Machine offers both high flexibility and mass production of tailored thermoplastic laminates with reduced scrap. Fully consolidated multi-layer laminates with different fiber directions and minimized scrap (tailored blanks) can be produced in cycle times below five seconds with this new scalable machine setup. This individualized mass production is accomplished by a combination of laser-assisted tape placement with in-situ consolidation and a piece-flow principle, which is state of the art in the printing industry but has not been used in such a way within composite production. The achievable productivity is enhanced to more than 500 kg/hour by this piece-flow principle with carriers moved through multiple application stations which are equipped with multiple tape placement applicators. The new machine is scalable: multiple application stations can be added, e.g. for each layer one station for mass production or for each fiber direction one station with a carrier-conveyor carousel: here the carriers are moved multiple times through the application stations.

The system will be commercialized by some of the industrial partners in 2019. The real machine setup has been presented at the AZL booth during the JEC World 2019 in Paris.

The follow-up project has just started and is still open to join for industrial partners. This follow- up project comprises a further upscale of the machine system as well as a preparation of the commercialization by long-term durability tests and further process optimizations using different tape materials.
